ThermaCAM B660
The FLIR B660 high-definition infrared camera
delivers maximum thermal sensitivity and imaging
features for advanced building and energy surveys.

• New 640 x 480 Infrared Detector
• Powerful Thermal Sensitivity:<45mK
• Dew Point and Insulation Alarms
• Dynamic Details Enhancement (DDE)
• TripleFusion Picture in Picture
• 3.2 Mpixel Visible Light Camera
• Easy Text and Voice Annotation
• Built-in Geographic Positioning System(GPS)

New and Improved Detector
The B660 infrared camera includes a new 640 X 480 infrared detector that delivers four times greater detail than cameras with 320 x 240 IR resolution. The new detector also delivers optimum <45 mK thermal sensitivity at +30?C (+86?F) to help capture the finest image detail to determine trouble spots in buildings and infrastructure.

The B660’s high-resolution capability enables accurate readings to be taken at greater distances,which helps ensure productivity, safety,
and cost-effectiveness.

Dynamic Details Enhancement (DDE)
FLIR’s exclusive DDE capability brings out detail in IR images. With the introduction of the B660, FLIR is implementing DDE for the first time in a commercial infrared camera. FLIR Systems is the global leader in infrared cameras withmore than 40 years experience developing cameras for government,military, and research.

Record GPS info with images
Forget typing addresses or trying to recall where images were taken. The GPS technology in the B660 automatically records location information for you, so you can conduct IR surveys quickly and efficiently.

Survey at Safe Distances
For those applications where safe distances need to be maintained, the B660 can be used with interchangeable lenses and an optional FLIR handheldWireless LAN-based remote control and display. The B660 also features a large target-distance to spot-size ratio for accurate measurements and analyses. This enables professionals to conduct quick, easy, and safe IR inspections.

Viewfinder and LCD
The B660 includes a tiltable color viewfinder (800 X 600) and a high resolution LCD (1024 X 600). The tilt-able viewfinder is ideal for outdoor work, especially in bright sunlight. The LCD provides convenient and comfortable viewing for extensive survey work.

Productive Auto Focus
Manual and Auto Focus allows operators greater flexibility when collecting images in a range of settings. Auto Focus allows new users to be productive sooner and manual focus provides the added control when needed.

Safety Enhancing Laser LocatIR
The Laser LocatIR on the B660 boosts productivity. Simply push a button and the laser position you see on an object is automatically aligned and displayed in the IR image.

This feature makes it easier and safer for professionals to mark off trouble spots on roofs and structures. Laser LocatIR also helps overcome the tendency to finger-point – which can be a dangerous practice in high-voltage areas.
